Air Differential Pressure Transmitter HPT702

Availability:

100 in stock


Air Differential Pressure Transmitter HPT702 adalah Pemancar tekanan diferensial udara jarak rendah memberikan solusi akurat yang tersedia dari 0-50pa hingga 0-500Kpa DP. Menggabungkan sensor silikon dan teknologi elektronik terbaru, pemancar 4-20mA sepenuhnya dikompensasi suhu untuk stabilitas tak tertandingi pada tekanan sangat rendah.

Rp3,800,000

100 in stock

Compare

Air Differential Pressure Transmitter HPT702 adalah Pemancar tekanan diferensial udara jarak rendah memberikan solusi akurat yang tersedia dari 0-50pa hingga 0-500Kpa DP. Menggabungkan sensor silikon dan teknologi elektronik terbaru, pemancar 4-20mA sepenuhnya dikompensasi suhu untuk stabilitas tak tertandingi pada tekanan sangat rendah.

Spesifikasi Teknis :
Parameter : HPT702
Pressure Range : ±100Pa~100KPa optional
Safe overload : 200% F.S.
Burst Pressure : 500% F.S.
Accuracy : 1.0%F.S; 0.5%F.S; 0.25%F.S optional
Long Time Stability : ≤0.2%F.S/Year
Working Temp : -40℃~85℃
Storage Temp : -40℃~105℃
Temperature compensation : 0℃~50℃
Zero Point Temp Drift : ≤±0.03%F.S/℃
Full Scale Temp Drift : ≤±0.03%F.S/℃
Max Static Pressure : ≤200 kPa
Medium compatible : <5 kPa, non-corrosive gas. ≥5 kPa, compatible with 316L liquids
Electronic Wire :2 Wires ;3 Wires ;4 Wires
Output : 4~20mA; 0~5V / 0~10 V ;RS485 Modbus RTU
Power Supply : 12~ 30 V DC ; 12~30 V / 15~30 V 12~30 V
Load resistance : R=(U-12.5) / 0.02-RD (RD is cable inner resistance)
Electronic connection : Fixed cable outlet
Materials of diaphragm :Silica gel / 316L
Proof grade : IP66
Pressure connect port& Materials : Φ8 gas port, M10 SUS304 Stainless steel and LY12
Response time : ≤1ms
Adjustment : Support adjustable zero and span.
Pressure Type : Differential pressure (Gauge pressure)
EMC Standard : Approving
Weight : Around 0.2KG (excluding package)

Keuntungan
Solusi terbaik untuk pengukuran tekanan diferensial udara, gas yang mudah terbakar dan meledak atau sistem HAVC.
Fungsi kompensasi suhu otomatis cocok untuk kondisi kerja yang lebih parah.
Cangkang paduan aluminium tahan ledakan lebih cocok untuk mengukur tekanan diferensial gas yang mudah terbakar dan meledak.
Produsen tekanan diferensial.

Aplikasi:
Perangkat pendeteksi kebocoran
Ketel
Pembuatan bir
Lokomotif
Gas non-korosif non-konduktif
Tekanan diferensial udara HAVC

Weight1 kg
Dimensions0.0000 × 0.0000 × 0.0000 cm

Spesifikasi Teknis :
Parameter : HPT702
Pressure Range : ±100Pa~100KPa optional
Safe overload : 200% F.S.
Burst Pressure : 500% F.S.
Accuracy : 1.0%F.S; 0.5%F.S; 0.25%F.S optional
Long Time Stability : ≤0.2%F.S/Year
Working Temp : -40℃~85℃
Storage Temp : -40℃~105℃
Temperature compensation : 0℃~50℃
Zero Point Temp Drift : ≤±0.03%F.S/℃
Full Scale Temp Drift : ≤±0.03%F.S/℃
Max Static Pressure : ≤200 kPa
Medium compatible : <5 kPa, non-corrosive gas. ≥5 kPa, compatible with 316L liquids
Electronic Wire :2 Wires ;3 Wires ;4 Wires
Output : 4~20mA; 0~5V / 0~10 V ;RS485 Modbus RTU
Power Supply : 12~ 30 V DC ; 12~30 V / 15~30 V 12~30 V
Load resistance : R=(U-12.5) / 0.02-RD (RD is cable inner resistance)
Electronic connection : Fixed cable outlet
Materials of diaphragm :Silica gel / 316L
Proof grade : IP66
Pressure connect port& Materials : Φ8 gas port, M10 SUS304 Stainless steel and LY12
Response time : ≤1ms
Adjustment : Support adjustable zero and span.
Pressure Type : Differential pressure (Gauge pressure)
EMC Standard : Approving
Weight : Around 0.2KG (excluding package)
