Differential Pressure Transducers HPT700H


Differential Pressure Transducers HPT700H adalah Transduser Tekanan Diferensial Industri Standar HPT700H mendapatkan semua karakteristik kinerja hebat dari Transduser Silikon Mesin Mikro dalam model tekanan diferensial baja tahan karat 316 ini.

Rp3,999,000 Rp4,500,000

Differential Pressure Transducers HPT700H adalah Transduser Tekanan Diferensial Industri Standar HPT700H mendapatkan semua karakteristik kinerja hebat dari Transduser Silikon Mesin Mikro dalam model tekanan diferensial baja tahan karat 316 ini.

Spesifikasi Teknis :
Pressure Range : 10~50KPa ;51~100KPa ; 101~200KPa ; 201~1000KPa
High port overload : 50~500 kPa ; 500~1000 KPa ; 10~20 Bar ; 20~40Bar
Low port overload : 30~150KPa ; 150~300KPa ; 300~600KPa ; 600~1000KPa
Max Static Pressure : 50 bar ; 100 bar ; 150bar ; 200bar
Accuracy :≤±0.5%F.S (Typical); ≤±0.25%F.S (by customized);
Stability : 0.1%F.S/Year
Ambient Temp Span : -40℃~85℃
Medium Temp Span : -40℃~85℃ / -40℃~125℃(with cool device)
Storage Temp : -40℃~105℃
Temperature compensation : 0℃~50℃
Zero Temp Drift : 0.02%F.S/℃
Span Temp Drift : 0.02%F.S/℃
Medium compatible : Compatible with 316 Stainless Steel
Power Supply : 7~30Vdc ; 8~30Vdc ; 15~30Vdc ; 7-30Vdc
Load resistance : (U-10)/0.02(Ω ) >100kΩ ; Max 255
Insulate resistance : >100M Ω @100V
Electronic connection : Fixed cable and water proof IP67 (HPT700-S); Terminal Box DIN43650 IP65 (HPT700-H,HPT700-G)
Pressure connect port : 1/4’’-18NPT Female; G1/4’’ Male; G1/2’’ Male; RG=Ø8/ Ø 10gas mouth optional. (by Customized)
Process structure : All-Welded Construction (non-O-rings)
Response time : ≤10ms
Pressure Type : Differential Pressure (Gauge Type)
Certificate : ExiaIICT6 and CE Certificate.
EMC Standard : EN 61326-1:2013; EN 61326-2-3:2013 EN 61000-6-2:2005; EN61000-6-4:2007+A1
Water Proof : IP65 to IP68 optional by model
Weight : Net weight is about 0.4KG, Full Packing weight is about 0.7KG (Including 3 Meters Cable)

Keuntungan
Inti Silikon Mesin Mikro Presisi;
Bukti Ledakan dan Non-Incendive Tersedia.
Stabilitas Tinggi, Drift Rendah.
316 Konstruksi Baja Tahan Karat yang Dilas.
Kinerja Suhu Premium.

Aplikasi:
Kontrol Proses
Pengukuran Level Tangki
Memfilter Pemantauan Kinerja
Cairan Korosif dan Pengukuran Gas
Pengukuran dan Kontrol Tekanan Statis

Weight 2 kg

Spesifikasi Teknis :
Pressure Range : 10~50KPa ;51~100KPa ; 101~200KPa ; 201~1000KPa
High port overload : 50~500 kPa ; 500~1000 KPa ; 10~20 Bar ; 20~40Bar
Low port overload : 30~150KPa ; 150~300KPa ; 300~600KPa ; 600~1000KPa
Max Static Pressure : 50 bar ; 100 bar ; 150bar ; 200bar
Accuracy :≤±0.5%F.S (Typical); ≤±0.25%F.S (by customized);
Stability : 0.1%F.S/Year
Ambient Temp Span : -40℃~85℃
Medium Temp Span : -40℃~85℃ / -40℃~125℃(with cool device)
Storage Temp : -40℃~105℃
Temperature compensation : 0℃~50℃
Zero Temp Drift : 0.02%F.S/℃
Span Temp Drift : 0.02%F.S/℃
Medium compatible : Compatible with 316 Stainless Steel
Power Supply : 7~30Vdc ; 8~30Vdc ; 15~30Vdc ; 7-30Vdc
Load resistance : (U-10)/0.02(Ω ) >100kΩ ; Max 255
Insulate resistance : >100M Ω @100V
Electronic connection : Fixed cable and water proof IP67 (HPT700-S); Terminal Box DIN43650 IP65 (HPT700-H,HPT700-G)
Pressure connect port : 1/4’’-18NPT Female; G1/4’’ Male; G1/2’’ Male; RG=Ø8/ Ø 10gas mouth optional. (by Customized)
Process structure : All-Welded Construction (non-O-rings)
Response time : ≤10ms
Pressure Type : Differential Pressure (Gauge Type)
Certificate : ExiaIICT6 and CE Certificate.
EMC Standard : EN 61326-1:2013; EN 61326-2-3:2013 EN 61000-6-2:2005; EN61000-6-4:2007+A1
Water Proof : IP65 to IP68 optional by model
Weight : Net weight is about 0.4KG, Full Packing weight is about 0.7KG (Including 3 Meters Cable)
