Water Quality Sensors

Instrument Features
The unique design makes this product have lower failure rate, lower maintenance, lower reagent consumption and higher cost performance than similar products.
Select valve assembly: select the reagent sampling sequence, the channels are flexible and diverse, the functions are changeable, and it has the advantages of minimum dead volume, easy maintenance and long life.
Micro metering component: The precise metering of reagents is realized through the visual photoelectric system, which overcomes the quantitative error caused by the wear of the peristaltic pump tube; at the same time, the precise quantification of micro-reagents is realized, and each dose is only 1 ml, which greatly reduces the use of reagents quantity.

SUP-TDS210-B conductivity meter with different electrodes can be well adapted to on-site measurement.
Whether it is common tap water, boiler feed water, pure water, ultra-pure water, industrial water, sewage, etc.

Features
-Using (4 ~ 20mA) is transmission output isolation, less affected by interference.
-Using isolated RS485 communication, via Modbus-RTU protocol can be easily linked into a computer.
-With configuration temperature manual and automatic compensation functions.
-Has the function of setting high and low alarms and hysteresis.
-It has the function of setting buzzer and LCD backlight switch.
-Has the function of setting high and low alarms and hysteresis.
-It has the function of setting buzzer and LCD backlight switch.

SUP-DO-7012 is based on luminescent optics technology.
Optical dissolved oxygen sensors are approved by ASTM International Method D888-05.

Features
1. Imported hash sensor, more accurate and reliable
2. Service life is 1-2 years
3. It can be used in harsh working conditions such as aeration tanks, sewage treatment, marine aquaculture, etc.

Fluorescence dissolved oxygen meter is an intelligent online optical analysis instrument, which is widely used in continuous monitoring of dissolved oxygen, saturation and temperature in solutions such as thermal power, chemical fertilizers, metallurgy, environmental protection, pharmaceuticals, biochemicals, food and tap water.
The continuous monitoring data can be remotely monitored and recorded by connecting the recorder through the transmission output, and can also be connected to the RS485 interface through the Modbus-RTU protocol, which can be easily connected to the computer for monitoring and recording.

Features
-The circuit design adopts modular design.
-Isolation transmission output is adopted, which is less affected by interference.
-Using isolated RS485 communication.
-It can measure dissolved oxygen, saturation and temperature.
-Air calibration can be performed.
-With automatic temperature compensation function.
-Has the function of setting high and low alarms and hysteresis.
-It has the function of setting buzzer and LCD backlight switch.
-Language can be selected, currently supports Chinese and English.

SJG-3083 industrial acid-base concentration meter is our company’s new generation of Chinese (English) microcomputer type high-end instrument, with Chinese (English) display, Chinese (English) menu operation, full intelligence, multi-function, measurement performance High, environmental adaptability and other characteristics. It can be widely used in thermal power, chemical and other industries. It is suitable for checking the concentration of regeneration liquid in the process of producing high-purity water by ion exchange, or for preparing pickling liquid for boilers and pipelines, and continuously monitoring the concentration of acid, alkali and salt in the solution.

Electrode Features
1. Adopt international advanced solid dielectric and large-area PTFE liquid junction, which is not easy to block and easy to maintain
2. The long-distance reference diffusion path greatly prolongs the service life of the electrode in harsh environments
3. There is no need to supplement the dielectric, and the maintenance is small
4. High measurement accuracy, fast response and good repeatability

Electrode Features
1. Adopt international advanced solid dielectric and large-area PTFE liquid junction, which is not easy to block and easy to maintain
2. The long-distance reference diffusion path greatly prolongs the service life of the electrode in harsh environments
3. There is no need to supplement the dielectric, and the maintenance is small
4. High measurement accuracy, fast response and good repeatability

Basic Principles of PH Electrodes
The electrodes used in pH measurement are also known as galvanic cells. A galvanic cell is a system that converts chemical energy into electrical energy. The voltage of this battery is called the electromotive force (EMF). This electromotive force (EMF) consists of two half-cells. One of the half-cells is called the measuring cell, and its potential is related to a specific ionic activity; the other half-cell is the reference half-cell, usually called the reference electrode, which is generally connected to the measuring solution and is connected to the measuring instrument.

DDG-2090 simplifies functions on the basis of guaranteed performance, clear display, easy operation and excellent test performance make it very cost-effective. It can be widely used in thermal power, chemical fertilizer, metallurgy, environmental protection, pharmaceutical, biochemical, food and tap water and other solutions in the continuous monitoring of conductivity values.

DDG-3080 industrial conductivity meter is our company’s new generation of Chinese (English) microcomputer high-end instrument, with Chinese (English) display, Chinese (English) menu operation, full intelligence, multi-function, high measurement performance , strong environmental adaptability and so on. It can be widely used in thermal power, chemical fertilizer, metallurgy, environmental protection, pharmaceutical, biochemical, food and tap water and other solutions for continuous monitoring of conductivity values.

Instrument features : new layout design, cast aluminum shell, metal texture, to create a high-grade E era water meter!
Full Chinese display, friendly interface, multi-parameter simultaneous display: simultaneous display of conductivity, output current, temperature, time and status on one screen. Adopt high-resolution dot matrix liquid crystal display module, all data, status and operation prompts are displayed in Chinese (English), and there is no symbol or code defined by the manufacturer at all.
