The SUP-PTU100 turbidity meter has a built-in microprocessor and is suitable for turbidity monitoring in sewage plants, water plants, water stations, surface water, industry and other fields, such as: sewage plant sedimentation tanks, paper slurry tanks, lifting pump stations, oxidation ditch turbidity Degree measurement, etc.
Features
1. High protection level
2. Using ISO7027 technology, continuous and accurate measurement, determination of sludge concentration value without being affected by chromaticity
3. Built-in self-diagnosis function to ensure accurate data
4. Simple installation and calibration
Specifications
Model: SUP-PTU100
Display: 2.8-inch LCD
Measuring range: 0.01~4000NTU
Accuracy: ±1%
Display resolution: 0.01NTU
Stability: ±1%F.S/y
Input resistence: –
Temperature range: -10~60℃
Temperature compensation: –
Power supply: AC220V±10%, 50Hz
Relay output: High relay/ low relay, 3A/250VAC
Communication: RS485 MODBUS RTU protocol
Signal output: 4~20mA
Overall dimension (mm): 100x100x150mm
Panel cutout size (mm): 92.5⁺¹x92.5⁺¹mm
