Iridium Satellite GPS Tracker


TR130 is true global satellite communication system based on iridium SBD and GPRS hybrid technology. It is mainly designed for the high value assets tracking with no blind area on the earth. The device provides real time tracking with lower monthly tracking costs while delivering 100% global coverage and web-based fleet monitoring. It works far beyond the reach of WiFi and GSM network. It works on the top of mountain, the middle of desert, the middle of any ocean, isolated islands, as well as the polar regions.

Rp12,800,000

Iridium Satellite GPS Tracker
Model : TR130

Introduction :
TR130 is true global satellite communication system based on iridium SBD and GPRS hybrid technology. It is mainly designed for the high value assets tracking with no blind area on the earth. The device provides real time tracking with lower monthly tracking costs while delivering 100% global coverage and web-based fleet monitoring. It works far beyond the reach of WiFi and GSM network. It works on the top of mountain, the middle of desert, the middle of any ocean, isolated islands, as well as the polar regions.

Features:
1. Dual mode communications: Iridium SBD module and GPRS module
2. Auto switch communication mode, GPRS is priority mode. It switches to SBD mode wherever there is no GPRS signal.
3. No blind area: Signals cover all global areas including remote areas, sea, air, mountain, desert and the polar regions
4. Geo-fence

Specifications:
Iridium receiver parameters
Iridium module: Iridium 9602n
Frequency: 1616 ~ 1626.5 MHz
Receiving sensitivity: -118.5dBm at 50W
Global coverage: no blind areas
Duplex mode: TDD (Time Division Duplex) Upstream data: maximum length: 340 bytes
Downstream: maximum length is 270 bytes
Transmission delay: 10 ~60 seconds (because of galaxy switch)
Input/ Output impedance: 50Ω
Multiplex mode: TDMA/FDMA
Iridium antenna and interface: external antenna, SMA interface

Weight 2000 g

Specifications:
Iridium receiver parameters
Iridium module: Iridium 9602n
Frequency: 1616 ~ 1626.5 MHz
Receiving sensitivity: -118.5dBm at 50W
Global coverage: no blind areas
Duplex mode: TDD (Time Division Duplex) Upstream data: maximum length: 340 bytes
Downstream: maximum length is 270 bytes
Transmission delay: 10 ~60 seconds (because of galaxy switch)
Input/ Output impedance: 50Ω
Multiplex mode: TDMA/FDMA
Iridium antenna and interface: external antenna, SMA interface
