Direct Current Voltage Transducer


Direct Current Voltage Transducer

Model:DVV600
The DVV600 is special for measuring 0~600V direct current voltage. It is an industrial class, high reliability, low-power consumption, high stability and high precision analog transducer.

Rp2,220,000

Direct Current Voltage Transducer

Model:DVV600
The DVV600 is special for measuring 0~600V direct current voltage. It is an industrial class, high reliability, low-power consumption, high stability and high precision analog transducer.

Introduction:
The DVV600 is special for measuring 0~600V direct current voltage. It is an industrial class, high reliability, low-power consumption, high stability and high precision analog transducer.
The DVV600 is used widely as a direct current voltage measure of Base Transceiver Station, diesel generator rooms, engine room, transformer substations, telecommunication equipment rooms, power supply systems and so on.



Weight 500 g

Spesification:
Rated Power Input:12VDC
Measurement Range:0~600VDC
Output Voltage:0~5V
Precision:+/-1%;
Relative Humidity:10~90%RH.;
Operation Temperature:-30~80℃;
Power Consumption:<20mA
Dimension:(HxWxD) 98x56x42mm;
Net Weight:98g.
