Infrared Temperature Sensor RK310-03


RK310-03 Dust Sensor using laser scattering principle, detecting the existence of dust particle concentration in the air, the minimum can detect 1.0um particles, has a good consistency and stability.
According to different usage environment, there are indoor type and outdoor type to select.

RK310-03 Dust Sensor using laser scattering principle, detecting the existence of dust particle concentration in the air, the minimum can detect 1.0um particles, has a good consistency and stability.
According to different usage environment, there are indoor type and outdoor type to select.

Specifications
Range: 0-+100℃
Accuracy: ± 1%
Repeatability: ± 0.5 ° C
Power Supply: 12-30VDC
Output Signal: 4-20mA, 0-5V, RS485 optional
The measured object size and measurement ratio: 20: 1
Emissivity: 0.95
Response time: 100ms
Response wavelength: 8-14um
Ingress Protection: IP65
Storage: -20-+80℃@20%-90%RH
Shell material: 304ss
Mounting bracket: 304ss

SKU: RK310-03 Category:
