Drop-in level gauge SUP-P260


The SUP-P260 submersible liquid level gauge uses a high-performance diffused silicon piezoresistive pressure sensor as the measuring element, accurately measures the hydrostatic pressure proportional to the liquid level depth, and converts it into a standard (current or voltage) through the signal conditioning circuit Signal output, establishes the linear correspondence between the output signal and the liquid depth, and realizes the measurement of the liquid depth.
The product has high precision and small volume. It can be directly put into the liquid to measure the liquid height from the end of the transmitter to the liquid level, which is easy to use. It is suitable for liquid level measurement and control in the fields of petroleum, chemical industry, power plant, urban water supply, and hydrological exploration. After long-term aging and stability screening, the product performance is stable and reliable, and it can be applied to open-air sites with harsh environments, and can display liquid level on site. Zero point, full range can be migrated.

Features
1. Micro amplifier, voltage, current, frequency signal output
2. Anti-clogging, easy to clean
3. The integrated laser is powerful and the shell does not leak
4. Surface CNC diamond knife polishing and polishing

The SUP-P260 submersible liquid level gauge uses a high-performance diffused silicon piezoresistive pressure sensor as the measuring element, accurately measures the hydrostatic pressure proportional to the liquid level depth, and converts it into a standard (current or voltage) through the signal conditioning circuit Signal output, establishes the linear correspondence between the output signal and the liquid depth, and realizes the measurement of the liquid depth.
The product has high precision and small volume. It can be directly put into the liquid to measure the liquid height from the end of the transmitter to the liquid level, which is easy to use. It is suitable for liquid level measurement and control in the fields of petroleum, chemical industry, power plant, urban water supply, and hydrological exploration. After long-term aging and stability screening, the product performance is stable and reliable, and it can be applied to open-air sites with harsh environments, and can display liquid level on site. Zero point, full range can be migrated.

Features
1. Micro amplifier, voltage, current, frequency signal output
2. Anti-clogging, easy to clean
3. The integrated laser is powerful and the shell does not leak
4. Surface CNC diamond knife polishing and polishing

Specifications
Model: SUP-P260
Range: 0-50m
Accuracy: 0.3/0.5% (optional)
Temperature drift: ≤0.01F.S/℃
Medium temperature: -40~60℃
Overload pressure: 200%F.S
Power supply: 12VDC, 24VDC
Enviroment temperature: 0℃-85℃
Ingress protection: IP68
Output signal: 4-20mA, 1-5V, 0~10mA
Relay output: –
Communication: RS485 (optional)
Material: Diaphragm: SS316L; Body: SS304L; Cable: Polyurethane
Process connection: –

SKU: SUP-P260 Category:
