Data Logger with LCD display


RK600-07 Data Logger adalah perangkat yang digunakan untuk mengambil, menyimpan, mengirim, dan mengelola data. ia dapat terhubung dengan 32 parameter secara bersamaan, memiliki pengaturan dan layar LCD warna, dapat berkomunikasi dengan cara kabel atau nirkabel, dan menyediakan protokol komunikasi yang mudah digunakan untuk pengembangan sekunder.

Rp12,900,000 Rp13,980,000

RK600-07 Data Logger adalah perangkat yang digunakan untuk mengambil, menyimpan, mengirim, dan mengelola data. ia dapat terhubung dengan 32 parameter secara bersamaan, memiliki pengaturan dan layar LCD warna, dapat berkomunikasi dengan cara kabel atau nirkabel, dan menyediakan protokol komunikasi yang mudah digunakan untuk pengembangan sekunder.

Spesifikasi:
Item : RK600-07A ;RK600-07B
Display : 7” color touch screen with backlight ;7” color touch screen with backlight
OS : / ; Android4.0.3
Screen sleep : Support ;Support
Backlight adjustable : Support ; Support
Communication status indication : Support ; Support
Internal storage : 64M(Data stored once every hour for 6 years, once every 10 minutes for 1 year);64M(Data stored once every hour for 6 years, once every 10 minutes for 1 year)
External storage : 60GB ;60GB
MICROTHINGS Cloud : Support,Need GPRS/2G/3G/4G Module; Not support
User cloud : Support,Need GPRS/2G/3G/4G Module ; Not support
API : Support,Need GPRS/2G/3G/4G Module ;Not support
Remote monitoring : Not support ; Support Windows,Mac & Android
Video & photo : Via MICROTHINGS cloud; Not support
Sensor connection : Waterproof connector Waterproof connector
Communication interface: RS485 RS485,Ethernet,GPRS/2G/3G/4G,WIFI;RJ45 Ethernet(optional)/GPRS/2G/3G/4G(optional);/Lora(optional)Lora(optional);Zigbee(optional)Zigbee(optional)
Communication protocol: Modbus-Rtu;Modbus-Rtu,Modbus-Tcp;Modbus-Tcp(with Ethernet module) /
Supply: Solar power,DC12-24V,AC100-240V Solar power,DC12-24V,AC100-240V
Measurement parameters: 32 max.,support 16 parameters upload to cloud platform 32 max.
Recording interval: 1-240min settable; 1-240min settable
U_disk download : Support; Support
Relay output: customized customized
Average consumption : <3.5W <3.5W
CPU : ARMCortex-A8 64bit (600MHZ); ARMCortex-A8 64bit (720MHZ)
ESD : Class 4,±8kV Class 4,±8kV
Operation temperature: -40-+75℃ -40-+75℃
Shock : 10-25Hz(X,Y,Z 2g@30min) 10-25Hz(X,Y,Z 2g@30min)
FCC : Class A Class A
CE : EN55022 & EN55024 EN55022 & EN55024
Protection box : 400*500*200mm,support solar power system 400*500*200mm,support solar power system
IP(with protection box) IP55 IP55

Weight 2 kg

Spesifikasi:
Item : RK600-07A ;RK600-07B
Display : 7” color touch screen with backlight ;7” color touch screen with backlight
OS : / ; Android4.0.3
Screen sleep : Support ;Support
Backlight adjustable : Support ; Support
Communication status indication : Support ; Support
Internal storage : 64M(Data stored once every hour for 6 years, once every 10 minutes for 1 year);64M(Data stored once every hour for 6 years, once every 10 minutes for 1 year)
External storage : 60GB ;60GB
MICROTHINGS Cloud : Support,Need GPRS/2G/3G/4G Module; Not support
User cloud : Support,Need GPRS/2G/3G/4G Module ; Not support
API : Support,Need GPRS/2G/3G/4G Module ;Not support
Remote monitoring : Not support ; Support Windows,Mac & Android
Video & photo : Via MICROTHINGS cloud; Not support
Sensor connection : Waterproof connector Waterproof connector
Communication interface: RS485 RS485,Ethernet,GPRS/2G/3G/4G,WIFI;RJ45 Ethernet(optional)/GPRS/2G/3G/4G(optional);/Lora(optional)Lora(optional);Zigbee(optional)Zigbee(optional)
Communication protocol: Modbus-Rtu;Modbus-Rtu,Modbus-Tcp;Modbus-Tcp(with Ethernet module) /
Supply: Solar power,DC12-24V,AC100-240V Solar power,DC12-24V,AC100-240V
Measurement parameters: 32 max.,support 16 parameters upload to cloud platform 32 max.
Recording interval: 1-240min settable; 1-240min settable
U_disk download : Support; Support
Relay output: customized customized
Average consumption : <3.5W <3.5W
CPU : ARMCortex-A8 64bit (600MHZ); ARMCortex-A8 64bit (720MHZ)
ESD : Class 4,±8kV Class 4,±8kV
Operation temperature: -40-+75℃ -40-+75℃
Shock : 10-25Hz(X,Y,Z 2g@30min) 10-25Hz(X,Y,Z 2g@30min)
FCC : Class A Class A
CE : EN55022 & EN55024 EN55022 & EN55024
Protection box : 400*500*200mm,support solar power system 400*500*200mm,support solar power system
IP(with protection box) IP55 IP55
