CO Gas Detector

Availability:

100 in stock


CO Gas Detector adalah jenis pemantauan konsentrasi gas dalam berbagai jenis situasi atau saluran pipa 24 jam terus menerus dipasang di dinding jenis detektor gas. Menggunakan sensor merek pertama di dunia, dan teknologi proses mikro canggih, dengan tampilan data, respons cepat, presisi tinggi, dan stabilitas yang baik. Didukung oleh 24V DC, dengan 4-20mA, RS485, output sinyal relai. Tahan ledakan, cocok untuk berbagai jenis situasi.

Rp6,000,000Rp20,480,000

Compare

YT-95H-CO GAS Detector adalah jenis pemantauan konsentrasi gas dalam berbagai jenis situasi atau saluran pipa 24 jam terus menerus dipasang di dinding jenis detektor gas. Menggunakan sensor merek pertama di dunia, dan teknologi proses mikro canggih, dengan tampilan data, respons cepat, presisi tinggi, dan stabilitas yang baik. Didukung oleh 24V DC, dengan 4-20mA, RS485, output sinyal relai. Tahan ledakan, cocok untuk berbagai jenis situasi.

Features:
High accuracy & Reliable
Specialized in gas detection for 16 years, using world first brand sensors, high precision, the detection result is approved by the third testing organization.
Non-contacted control the device
With infrared ray controller, which can remote control alarm point settings, zero calibration, and address modification.
Online monitoring
24h continuously monitoring, data will real-time display.
Diversified output signals
4-20mA current signal output, compatible with different kinds of controllers.
RS485 digital signal output.
Relay signal output, to turn on/off ventilator, generators or other external devices.
Variety of installation methods
Wall mounted type, installed on the wall directly, real time monitoring.
Piping type, installed on the pipeline, monitoring the gas concentration inside.
Flow type, connected with external sampling pump and tube, measure the gas concentration in enclosed space.
Data transmission
Can be installed with computer software, to transmit the data to computer, workers can remote monitor the data.
High quality case
Die-cast aluminum case, strong and durable; Stainless steel case is available for choose, meeting the demand of different situations.
IP65 protection degree, water-proof, dust-proof, explosion-proof

Spesification
Detected Gas: CO/Carbon dioxide
Measure Range: 0-1ppm、0-10ppm、0-50ppm、0-100ppm、0-200ppm、(Standard Default: 0-500ppm、0-1000ppm)、0-5000ppm、0-100%LEL、etc
Install Method: Wall-mounted, piping type, flow-type
Output signal: 4-20mA, 1-5V, 2-10V, RS485, RS232, relays (optional)
Precision: ≤±3%F.S. (higher precision is available)
Zero shift: ≤±1%(F.S./year)
Display 4 digits: Nixie tube display.
Connection mode: G1/2 external thread explosion-proof flexible pipe
Thread Size: M45*2mm
Temperature: –20℃~50℃
Humidity: 0-95%RH (non-condensing)
Explosion-Proof: Ex dⅡCT6
Degree of protection: IP65
Material: Case: Die-cast aluminum
Sensor housing: Aluminum alloy or 316 stainless steel
Power: 12-36V DC
Dimensions: 180×150×90mm
Weight: ≤1.6kg
Approval: CE, CNEX explosion proof certificate, CMC(China Metrology Certification)
Warranty: 12 months

Application: Petrochemical & Chemical Industry, Municipal Engineering & Utilities, Agricultural & Environmental Protection, Electronic, Food & Pharmaceutical Industry, Other Industries

SKU: YT-95H-CO Category: Tag:
Weight2 kg
Type-Range

YT-95H-CO-10ppm, YT-95H-CO-1000ppm, YT-98H-CO-1000ppm, YT-98H-CO-10ppm, YT-96H-CO-1000ppm, YT-96H-CO-10ppm

Detected Gas: CH3OH/Methanol
Measure Range: 0-1ppm、0-10ppm、0-50ppm、0-100ppm、0-200ppm、 (Standard Default :0-500ppm、0-1000ppm) 、0-5000ppm、0-100%LEL、etc
Install Method: Wall-mounted, piping type, flow-type
Output signal: 4-20mA, 1-5V, 2-10V, RS485, RS232, relays (optional)
Precision: ≤±3%F.S. (higher precision is available)
Zero shift: ≤±1%(F.S./year)
Display 4 digits: Nixie tube display.
Connection mode: G1/2 external thread explosion-proof flexible pipe
Thread Size: M45*2mm
Temperature: –20℃~50℃
Humidity: 0-95%RH (non-condensing)
Explosion-Proof: Ex dⅡCT6
Degree of protection: IP65
Material :Case: Die-cast aluminum
Sensor housing: Aluminum alloy or 316 stainless steel
Power: 12-36V DC
Dimensions: 180×150×90mm
Weight: ≤1.6kg
Approval: CE, CNEX explosion proof certificate, CMC(China Metrology Certification)
Warranty: 12 months
